SSD WESTERN DIGITAL (W.D.) GREEN SN350 1TB NVME
The Western Digital Green SN350 1TB NVMe SSD is a budget-friendly PCIe NVMe storage drive designed for everyday computing. It offers fast read speeds up to 3200 MB/s, compact M.2 design, efficient power usage, and reliable performance.
Features
Overview
The Western Digital Green SN350 1TB NVMe SSD is an entry-level NVMe solid-state drive designed for faster storage performance compared to traditional SATA SSDs and hard disk drives. It is built using the PCIe Gen3 x4 interface with NVMe technology, enabling significantly faster data transfer speeds and improved system responsiveness.
This SSD comes in a compact M.2 2280 form factor, allowing easy installation in modern desktops and laptops that support NVMe drives. The SN350 series is designed for everyday computing tasks such as web browsing, office work, multimedia usage, and casual gaming.
The drive uses 3D NAND flash memory (QLC type) to provide reliable storage while maintaining a cost-effective price. It also supports Western Digital SSD Dashboard software, which allows users to monitor drive health, available storage, and performance.
Key Features
-
PCIe Gen3 x4 NVMe interface for faster performance than SATA SSDs
-
Sequential read speeds up to 3200 MB/s
-
Sequential write speeds up to 2500 MB/s
-
Compact M.2 2280 design for desktops and laptops
-
3D QLC NAND flash memory for efficient storage
-
Low power consumption suitable for laptops
-
Support for Western Digital SSD Dashboard software
-
3-year limited warranty
These features make the WD Green SN350 an affordable upgrade for users looking to improve system performance and storage capacity.
Technical Specifications
General Specifications
| Specification | Details |
|---|---|
| Brand | Western Digital |
| Model | WD Green SN350 |
| Model Number | WDS100T3G0C |
| Capacity | 1TB |
| Form Factor | M.2 2280 |
| Interface | PCIe Gen3 x4 NVMe |
| NVMe Version | NVMe 1.3 |
| NAND Type | 3D QLC NAND |
| Storage Type | Internal SSD |
These specifications ensure compatibility with most modern motherboards and laptops that support NVMe M.2 storage.
Performance Specifications
| Specification | Details |
|---|---|
| Sequential Read Speed | Up to 3200 MB/s |
| Sequential Write Speed | Up to 2500 MB/s |
| Random Read (4K) | Up to 300,000 IOPS |
| Random Write (4K) | Up to 400,000 IOPS |
These speeds allow faster system boot times, quicker application launches, and improved file transfer rates compared to SATA SSDs.
Endurance and Reliability
| Specification | Details |
|---|---|
| Endurance Rating | 100 TBW (Total Bytes Written) |
| MTTF (Mean Time to Failure) | Up to 1.0 million hours |
| Warranty | 3-Year Limited Warranty |
The endurance rating represents the amount of data that can be written to the drive over its lifespan while maintaining reliable performance.
Power Consumption
| Specification | Details |
|---|---|
| Average Active Power | 110 mW |
| Low Power Mode (PS3) | 25 mW |
| Sleep Mode (PS4) | 5 mW |
| Maximum Operating Power | 5 W |
The efficient power consumption makes the drive suitable for laptops and energy-efficient computing systems.
Environmental Specifications
| Specification | Details |
|---|---|
| Operating Temperature | 0°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Operating Vibration | 5 gRMS (10-2000 Hz) |
| Non-Operating Vibration | 4.9 gRMS (7-800 Hz) |
| Shock Resistance | 1500G @ 0.5 ms half-sine |
These specifications ensure stable operation under normal computing conditions.
Physical Specifications
| Specification | Details |
|---|---|
| Dimensions | 80 × 22 × 2.38 mm |
| Weight | ˜ 7.5 g |
| Form Factor | Single-sided M.2 2280 |
The slim and lightweight design allows installation in ultrabooks, mini PCs, and compact desktops.
Additional Technologies
The WD Green SN350 SSD incorporates several technologies to improve performance and reliability:
-
S.M.A.R.T monitoring for drive health tracking
-
TRIM support to maintain performance over time
-
Western Digital SSD Dashboard software for system monitoring
-
Shock resistance due to lack of moving parts
These features help maintain consistent performance and protect stored data.
Advantages
-
Affordable NVMe storage upgrade compared to high-end SSDs.
-
Faster than SATA SSDs and HDDs for everyday computing.
-
Compact M.2 design for modern laptops and desktops.
-
Energy-efficient operation suitable for portable devices.
-
Reliable brand reputation from Western Digital.
Conclusion
The Western Digital Green SN350 1TB NVMe SSD is a cost-effective storage solution designed for users who want faster performance than traditional storage devices without spending on premium NVMe drives. With PCIe Gen3 connectivity, sequential read speeds up to 3200 MB/s, and a compact M.2 form factor, it provides a noticeable improvement in system responsiveness and file transfer speed.
Although it is primarily designed for everyday computing and light workloads, its combination of reliable performance, low power consumption, and affordable pricing makes it an excellent choice for upgrading laptops or desktops to NVMe storage. Overall, the WD Green SN350 1TB SSD offers a solid balance of performance, efficiency, and value for general users.
Specifications
| SERIES | WDS100T3G0C |
|---|---|
| CAPACITY | 1TB |
| SIZE | M.2 2280 |
| INTERFACE | PCIE GEN3 |
| CONNECTION TYPE | NVME |
| READ SPEED | UPTO 3200 MBPS |
| WRITE SPEED | UPTO 2500 MBPS |
| TBW | UPTO 100 TBW |
